MP009737

The MULTICOMP PRO MP009737 is a Type 1 (SAE J1772) EV charging receptacle designed for high current Level 1 electric vehicle charging applications. Featuring 5 contacts and rated at 80A and 240V AC, this female connector is suitable for demanding EV charging systems in automotive, industrial, and energy environments. The connector is constructed with a durable thermoplastic housing and silver plated copper contacts, ensuring low contact resistance and reliable electrical performance. It offers high insulation resistance and a UL94 V 0 flammability rating, supporting safe operation in challenging conditions. Designed for use across a wide temperature range from 30°C to +50°C, the MP009737 is TÜV approved and compliant with European and international safety standards, making it a dependable solution for EV charging infrastructure.

• SAE J1772 type 1, female EV charging gun connector
• Rated voltage is 240VAC, current rating is 80A
• <gt/>1000Mohm (DC500V) insulation resistance, 0.5mohm maximum contact resistance
• Withstand voltage is 2000V, UL94 V-0 fire rating
• Insertion and extraction force is F≤100N
• Protection level is 3S, 5 contacts, charging level 1
• Thermoplastic plastics housing, copper silver coating conduct
• Environment temperature range from -30°C to +50°C
• TUV approved

Applications

Industrial, Automotive, Transportation, Energy, Electric Vehicle (EV) Charging
