We offer current sense SMD resistors from 25µΩ to 3kΩ, with power ratings from 50mW to 50W. We also have 0Ω devices to be used as jumpers.

What are Current Sense SMD Resistors?

Current Sense Resistors are similar to normal resistors but with very low resistance ratings and high power ratings. These shunt resistors of known resistor value (R) are placed in a current conducting path so that the entire current (I) which is to be measured flows through them. By measuring the voltage drop (V) across the resistor and then using simple Ohm’s Law (I=V/R), we can calculate the amount of current that flows through the circuit.

Why use a current sense resistor?

Sensing the current flow is an important requirement in many power and general electronics applications. Often, current sensing is essential to monitor and control an application; for example, a battery charger circuit requires current sensing capability to correctly charge the battery and to determine the charge current needed from the driver.

How do I choose a current sense resistor?

The first step in selecting a current sense resistor is based on understanding the application, particularly in terms of its maximum input voltage. Also, as it will be passing a heavy current (because it is connected in series with the load) its I2R losses will likely be significant even if its resistance value is small. Therefore, a knowledge of its power rating is essential.

The next step is to know the tolerance and package required for the shunt resistor. Less than 1% tolerance is a good choice. But if the application demands extra accuracy, 0.5% to 0.1% tolerance shunt resistors may be more appropriate.

After choosing the value, power rating, and tolerance, it is important to select a suitable package that is easy to solder as well as with a lower footprint for smaller PCB areas. Try to select a resistor with a very low TCR value, ideally below 100 ppm/°C.

Compare Selected Compare (0)

Sort by

Best Match

Best Match Price: Low to High Price: High to Low Stock: Low to High Stock: High to Low

Manufacturer Part No	Order Code	Description / Manufacturer	Price For	Price	Quantity	Resistance	Product Range	Resistor Case / Package	Power Rating	Resistance Tolerance	Resistor Technology	Resistor Type	Temperature Coefficient	Product Length	Voltage Rating	Product Width	Product Height	Operating Temperature Min	Operating Temperature Max	Qualification
						Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending
WSLP12065L000FEA	2420761 Data Sheet + RoHS	SMD Current Sense Resistor, 0.005 ohm, WSLP, 1206 [3216 Metric], 1 W, ± 1%, Metal Strip VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2420761 2420761RL in Re-reel	10+ Php38.50 25+ Php33.00 50+ Php29.70 100+ Php25.90 250+ Php23.20 500+ Php18.80 1000+ Php16.00 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.005ohm	WSLP	1206 [3216 Metric]	1W	± 1%	Metal Strip	-	± 110ppm/°C	3.2mm	-	1.6mm	0.635mm	-65°C	170°C	AEC-Q200
WSLP12065L000FEA	2420761RL Data Sheet + RoHS	SMD Current Sense Resistor, 0.005 ohm, WSLP, 1206 [3216 Metric], 1 W, ± 1%, Metal Strip VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Re-reel Packaging Options Suggested replacement for:2420761RL 2420761 in Cut Tape	100+ Php25.90 250+ Php23.20 500+ Php18.80 1000+ Php16.00	Restricted Item Minimum order of 100 items Multiples of 1 only Please enter a valid quantity Add Min: 100 Mult: 1	0.005ohm	WSLP	1206 [3216 Metric]	1W	± 1%	Metal Strip	-	± 110ppm/°C	3.2mm	-	1.6mm	0.635mm	-65°C	170°C	AEC-Q200
SR733ATTER100F	3542382RL Data Sheet + RoHS	SMD Current Sense Resistor, 0.1 ohm, SR73, 2512 [6432 Metric], 1 W, ± 1%, Thick Film KOA You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Re-reel Packaging Options Suggested replacement for:3542382RL 3542382 in Cut Tape	100+ Php23.30 500+ Php19.40 1000+ Php18.40	Restricted Item Minimum order of 100 items Multiples of 10 only Please enter a valid quantity Add Min: 100 Mult: 10	0.1ohm	SR73	2512 [6432 Metric]	1W	± 1%	Thick Film	-	± 100ppm/°C	6.3mm	-	3.1mm	0.6mm	-55°C	150°C	AEC-Q200
SR733ATTER100F	3542382 Data Sheet + RoHS	SMD Current Sense Resistor, 0.1 ohm, SR73, 2512 [6432 Metric], 1 W, ± 1%, Thick Film KOA You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:3542382 3542382RL in Re-reel	10+ Php30.90 100+ Php23.30 500+ Php19.40 1000+ Php18.40	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.1ohm	SR73	2512 [6432 Metric]	1W	± 1%	Thick Film	-	± 100ppm/°C	6.3mm	-	3.1mm	0.6mm	-55°C	150°C	AEC-Q200
ERJ8CWFR010V	2145283 Data Sheet + RoHS	SMD Current Sense Resistor, 0.01 ohm, ERJ8CW, 1206 [3216 Metric], 1 W, ± 1%, Thick Film PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2145283 2145283RL in Re-reel 2692845 in Full Reel	10+ Php25.00 50+ Php14.20 100+ Php10.50 500+ Php7.60 1000+ Php5.80	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.01ohm	ERJ8CW	1206 [3216 Metric]	1W	± 1%	Thick Film	-	± 75ppm/°C	3.2mm	-	1.6mm	0.65mm	-55°C	125°C	AEC-Q200

CRM2512-FX-R100ELF	1865265 Data Sheet Data Sheet + RoHS	SMD Current Sense Resistor, 0.1 ohm, CRM, 2512 [6432 Metric], 2 W, ± 1%, Thick Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1865265 1865265RL in Re-reel	10+ Php22.40	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.1ohm	CRM	2512 [6432 Metric]	2W	± 1%	Thick Film	-	± 100ppm/°C	6.3mm	-	3.1mm	0.6mm	-55°C	155°C	-

WSLP1206R0100FEA	2420762 Data Sheet + RoHS	SMD Current Sense Resistor, 0.01 ohm, WSLP, 1206 [3216 Metric], 1 W, ± 1%, Metal Strip VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2420762 2420762RL in Re-reel	10+ Php21.50 100+ Php18.70 250+ Php16.80 500+ Php16.50 1000+ Php13.60 4000+ Php13.10 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.01ohm	WSLP	1206 [3216 Metric]	1W	± 1%	Metal Strip	-	± 75ppm/°C	3.2mm	-	1.6mm	0.635mm	-65°C	170°C	AEC-Q200

CSS2H-3920R-L200FE	2908511 Data Sheet + RoHS	SMD Current Sense Resistor, 200 µohm, CSS2H-3920, 3921 [1052 Metric], 12 W, ± 1%, Metal Strip BOURNS You previously purchased this product. View in Order History	Each	1+ Php119.20 10+ Php92.40 100+ Php80.40 250+ Php69.60 500+ Php57.60 1000+ Php50.80 2000+ Php50.00 5000+ Php48.40 10000+ Php48.40 More Pricing...	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	200µohm	CSS2H-3920	3921 [1052 Metric]	12W	± 1%	Metal Strip	-	± 50ppm/°C	10mm	-	5.2mm	2.5mm	-55°C	170°C	AEC-Q200

CRA2512-FZ-R100ELF	1435952 Data Sheet + RoHS	SMD Current Sense Resistor, 0.1 ohm, CR, 2512 [6432 Metric], 3 W, ± 1%, Metal Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1435952 1435952RL in Re-reel	10+ Php17.80 100+ Php12.00 500+ Php11.40	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.1ohm	CR	2512 [6432 Metric]	3W	± 1%	Metal Film	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	AEC-Q200

CRA2512-FZ-R010ELF	1435947 Data Sheet + RoHS	SMD Current Sense Resistor, 0.01 ohm, CR, 2512 [6432 Metric], 3 W, ± 1%, Metal Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1435947 1435947RL in Re-reel 2691930 in Full Reel	10+ Php18.10 100+ Php12.10 500+ Php11.60	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.01ohm	CR	2512 [6432 Metric]	3W	± 1%	Metal Film	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	AEC-Q200

CRA2512-FZ-R020ELF	1435948 Data Sheet + RoHS	SMD Current Sense Resistor, 0.02 ohm, CR, 2512 [6432 Metric], 3 W, ± 1%, Metal Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1435948 1435948RL in Re-reel 2691931 in Full Reel	10+ Php17.30 100+ Php12.00 500+ Php11.50	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.02ohm	CR	2512 [6432 Metric]	3W	± 1%	Metal Film	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	AEC-Q200

CRA2512-FZ-R050ELF	1435950 Data Sheet + RoHS	SMD Current Sense Resistor, 0.05 ohm, CR, 2512 [6432 Metric], 3 W, ± 1%, Metal Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1435950 1435950RL in Re-reel	10+ Php18.10 100+ Php12.10 500+ Php11.40	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.05ohm	CR	2512 [6432 Metric]	3W	± 1%	Metal Film	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	AEC-Q200

CRM2512-FX-R100ELF	1865265RL Data Sheet Data Sheet + RoHS	SMD Current Sense Resistor, 0.1 ohm, CRM, 2512 [6432 Metric], 2 W, ± 1%, Thick Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Re-reel Packaging Options Suggested replacement for:1865265RL 1865265 in Cut Tape	10+ Php22.40	Restricted Item Minimum order of 100 items Multiples of 10 only Please enter a valid quantity Add Min: 100 Mult: 10	0.1ohm	CRM	2512 [6432 Metric]	2W	± 1%	Thick Film	-	± 100ppm/°C	6.3mm	-	3.1mm	0.6mm	-55°C	155°C	-

WSL2010R2000FEA	2368408 Data Sheet + RoHS	METAL STRIP RESISTOR, 0.2OHM, 1%, 2010, FULL REEL VISHAY You previously purchased this product. View in Order History	Each (Supplied on Full Reel) Full Reel	4000+ Php22.10	Restricted Item Minimum order of 4000 items Multiples of 4000 only Please enter a valid quantity Add Min: 4000 Mult: 4000	0.2ohm	WSL Series	2010 [5025 Metric]	500mW	± 1%	Metal Strip	-	± 75ppm/°C	5.08mm	-	2.54mm	0.635mm	-65°C	170°C	AEC-Q200

CRM2512-FX-R200ELF	2309096 Data Sheet + RoHS	SMD Current Sense Resistor, 0.2 ohm, CRM, 2512 [6432 Metric], 2 W, ± 1%, Thick Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2309096 2309096RL in Re-reel	10+ Php20.80 100+ Php13.30 500+ Php12.90 1000+ Php11.60	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.2ohm	CRM	2512 [6432 Metric]	2W	± 1%	Thick Film	-	± 100ppm/°C	6.3mm	-	3.1mm	0.6mm	-55°C	155°C	-

ERJ-8CWJR025V	3593118 Data Sheet + RoHS	CURRENT SENSE RESISTOR, 0.025OHM, 1W, 5% PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape	1+ Php27.60 10+ Php21.10 50+ Php12.00 100+ Php8.90 500+ Php6.50 1000+ Php5.00 More Pricing...	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	0.025ohm	AEC-Q200 ERJ8CW Series	1206 [3216 Metric]	1W	± 5%	Thick Film	-	± 50ppm/°C	3.2mm	-	1.6mm	0.65mm	-55°C	125°C	AEC-Q200

LRCS0805-0R5FT5	1506145 Data Sheet + RoHS	SMD Current Sense Resistor, 0.5 ohm, LRCS, 0805 [2012 Metric], 250 mW, ± 1%, Metal Film TT ELECTRONICS / WELWYN You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1506145 1506145RL in Re-reel	10+ Php5.70 100+ Php4.20 500+ Php3.30 1000+ Php3.00 2500+ Php2.70	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.5ohm	LRCS	0805 [2012 Metric]	250mW	± 1%	Metal Film	-	± 300ppm/°C	2.01mm	-	1.25mm	0.55mm	-55°C	155°C	-

WSR5R0100FEA	1107476 Data Sheet + RoHS	SMD Current Sense Resistor, 0.01 ohm, WSR, 4527 [11470 Metric], 5 W, ± 1%, Metal Strip VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1107476 1107476RL in Re-reel	1+ Php151.20 10+ Php132.00 100+ Php102.80 250+ Php88.00 500+ Php73.60 1000+ Php73.60 More Pricing...	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	0.01ohm	WSR	4527 [11470 Metric]	5W	± 1%	Metal Strip	-	± 75ppm/°C	11.56mm	-	6.98mm	2.41mm	-65°C	275°C	AEC-Q200

WSLP1206R0500FEA.	2411837 Data Sheet RoHS	28X3249 VISHAY You previously purchased this product. View in Order History	Each (Supplied on Full Reel) Full Reel	4000+ Php22.10	Restricted Item Minimum order of 4000 items Multiples of 4000 only Please enter a valid quantity Add Min: 4000 Mult: 4000	0.05ohm	WSL Series	1206 [3216 Metric]	1W	± 1%	Metal Strip	-	± 75ppm/°C	3.2mm	-	1.6mm	-	-	-	AEC-Q200

WSL36376L000FEA	3618291 Data Sheet + RoHS	RES, 0R006, 3W, 3637, METAL STRIP VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape	1+ Php91.20 10+ Php70.80 100+ Php59.60 250+ Php50.80	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	0.006ohm	WSL3637 Series	3637 [9194 Metric]	3W	± 1%	Metal Strip	-	± 50ppm/°C	9.14mm	-	9.4mm	0.635mm	-65°C	170°C	AEC-Q200

PA2512FKF070R004E	3496972 Data Sheet + RoHS	SMD Current Sense Resistor, 0.004 ohm, PA_E Series, 2512 [6432 Metric], 1 W, ± 1%, Metal Strip YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:3496972 3496972RL in Re-reel	10+ Php17.80 100+ Php12.80 500+ Php10.40 1000+ Php8.30 4000+ Php7.80 8000+ Php7.50 24000+ Php7.40 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.004ohm	PA_E Series	2512 [6432 Metric]	1W	± 1%	Metal Strip	-	± 100ppm/°C	6.35mm	-	3.18mm	0.63mm	-55°C	170°C	AEC-Q200

ULR2-R008FT2	1292494 Data Sheet + RoHS	SMD Current Sense Resistor, 0.008 ohm, ULR, 2512 [6432 Metric], 2 W, ± 1%, Metal Strip TT ELECTRONICS / WELWYN You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1292494 1292494RL in Re-reel	5+ Php41.20 100+ Php33.70 250+ Php29.00 500+ Php24.40 1000+ Php20.30 2000+ Php19.80 4000+ Php19.40 10000+ Php19.00 More Pricing...	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	0.008ohm	ULR	2512 [6432 Metric]	2W	± 1%	Metal Strip	-	± 50ppm/°C	6.35mm	-	3mm	0.6mm	-55°C	170°C	AEC-Q200

CRA2512-FZ-R100ELF	1435952RL Data Sheet + RoHS	SMD Current Sense Resistor, 0.1 ohm, CR, 2512 [6432 Metric], 3 W, ± 1%, Metal Film BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Re-reel Packaging Options Suggested replacement for:1435952RL 1435952 in Cut Tape	100+ Php12.00 500+ Php11.40	Restricted Item Minimum order of 100 items Multiples of 1 only Please enter a valid quantity Add Min: 100 Mult: 1	0.1ohm	CR	2512 [6432 Metric]	3W	± 1%	Metal Film	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	AEC-Q200

ULR1S-R01FT2	1621976 Data Sheet + RoHS	SMD Current Sense Resistor, 0.01 ohm, ULR, 1206 [3216 Metric], 1 W, ± 1%, Metal Strip TT ELECTRONICS / WELWYN You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1621976 1621976RL in Re-reel 2693554 in Full Reel	5+ Php41.60 100+ Php29.00 500+ Php20.90 1000+ Php17.00	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	0.01ohm	ULR	1206 [3216 Metric]	1W	± 1%	Metal Strip	-	± 50ppm/°C	3.2mm	-	1.6mm	0.6mm	-55°C	170°C	AEC-Q200

ERJ1TRQJR33U	2324366 Data Sheet + RoHS	SMD Current Sense Resistor, 0.33 ohm, ERJ1TR, 2512 [6432 Metric], 1 W, ± 5%, Thick Film PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2324366 2324366RL in Re-reel	10+ Php20.20 100+ Php15.20 500+ Php13.20 1000+ Php10.70 2000+ Php10.50 4000+ Php10.00 8000+ Php9.70 24000+ Php9.40 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.33ohm	ERJ1TR	2512 [6432 Metric]	1W	± 5%	Thick Film	-	± 200ppm/°C	6.4mm	-	3.2mm	0.6mm	-55°C	155°C	AEC-Q200
